TC-6110 / Windows 7 The 2013 Synmap OID Table
A-3
boot device.
pwrOnAfterPwrFail
1.3.6.1.4.1.8691.17.1.4.8.1
read
-write
Select power on after
power fail behavior.
pwrLanWakeUp
1.3.6.1.4.1.8691.17.1.4.8.3
read
-write
Enable/Disable wake on
LAN function
ality.
tempSensorsIndex
1.3.6.1.4.1.8691.17.1.5.1.1.1.1
read
-only
Reference index for each
observed device.
■
tempSensorsDevice
1.3.6.1.4.1.8691.17.1.5.1.1.1.2
read
-only
The name of the
temperature sensor we
are reading.
■
tempSensorsValue
1.3.6.1.4.1.
8691.17.1.5.1.1.1.3
read
-only
The temperature of this
sensor in mC.
■
voltSensorsIndex
1.3.6.1.4.1.8691.17.1.5.1.2.1.1
read
-only
Reference index for each
observed device.
voltSensorsDevice
1.3.6.1.4.1.8691.17.1.5.1.2.1.2
read
-only
The name of the device
we are reading.
voltSensorsValue
1.3.6.1.4.1.8691.17.1.5.1.2.1.3
read
-only
The voltage in mV.
accelerometerIndex
1.3.6.1.4.1.8691.17.1.5.1.3.1.1
read
-only
Reference index for each
observed device.
■
accelerometerAxis
1.3.6.1.4.1.8691.17.1.5.1.3.1.2
read
-only
The name of the
accelerometer axis we
are reading.
■
accelerometerValue
1.3.6.1.4.1.8691.17.1.5.1.3.1.3
read
-only
The accelerometer value
in mG.
■
accelerometerTimestamp
1.3.6.1.4.1.8691.17.1.5.1.3.1.4
read
-only
The timestamp when
accelerometer
measured.
■
ioDiNumber
1.3.6.1.4.1.8691.17.1.6.1.1.1
read
-only
Number of digital input
pin in current system.
diIndex
1.3.6.1.4.1.8691.17.1.6.1.1.2.1.1
read
-only
Reference index for each
digital input pin.
diPort
1.3.6.1.4.1.8691.17.1.6.1.1.2.1.2
rea
d-only
The port number of
digital input pin.
diValue
1.3.6.1.4.1.8691.17.1.6.1.1.2.1.3
read
-only
The digital input status, 0
is low, 1 is high.
diTrapEnable
1.3.6.1.4.1.8691.17.1.6.1.1.2.1.4
read
-write
Agent will send trap
message when digital
input p
in status changed
and this object enbeled.
ioDoNumber
1.3.6.1.4.1.8691.17.1.6.1.1.3
read
-only
Number of digital output
pin in current system.
doIndex
1.3.6.1.4.1.8691.17.1.6.1.1.4.1.1
read
-only
Reference index for each
digital output pin.
doPort
1.3.
6.1.4.1.8691.17.1.6.1.1.4.1.2
read
-only
The port number of
digital output pin.
