TC-6110 / Windows 7 Sample Code for TC-6110 Customization
B-3
for(int i = 0; i<LED_NUMBER; i++)
{
//Get digital input
led_no = i;
nLED = mxgpio_get_data(hGPIO, LEDMap[led_no]);
printf("LED[%d] = %d\n", led_no, nLED);
}
//Close LED
mxgpio_close(hGPIO);
break;
// if char == '3', Set the digital output
case 2:
//Get Port Number
getwchar();
printf("Input the LED Number (0 ~ %d) = \n",LED_NUMBER-1);
smode = getwchar();
led_no = _wtoi(&smode);
//Get Value
getwchar();
printf("Input the value (0 or 1) = ");
smode = getwchar();
data = _wtoi(&smode);
//Open LED
hGPIO = mxgpio_open();
//Set LED
nRet = mxgpio_set_data(hGPIO, LEDMap[led_no], data);
if(nRet==-1)
{
printf("Set led signal fail!\n");
}
else
{
printf("Set led signal success!\n");
}
//Close GPIO
mxgpio_close(hGPIO);
break;
}
getwchar();
sin = getwchar();
n = _wtoi(&sin);
} while (n != 0);
return 0;
}
