V2416 Linux User's Manual Managing Communications
3-23
# /etc/openvpn/bridge restart
On machine OpenVPN B, modify the remote address in configuration file
/etc/openvpn/tap0-br.conf.
# point to the peer
remote 192.168.8.173
dev tap0
secret /etc/openvpn/secrouter.key
cipher DES-EDE3-CBC
auth MD5
tun-mtu 1500
tun-mtu-extra 64
ping 40
up /etc/openvpn/tap0-br.sh
#comp-lzo
6. Next modify the routing table in /etc/openvpn/tap0-br.sh script file.
#----------------------------------Start-----------------------------
#!/bin/sh
# value after “-net” is the subnet behind the remote peer
route add -net 192.168.2.0 netmask 255.255.255.0 dev br0
#---------------------------------- end -----------------------------
And then configure the bridge interface in /etc/openvpn/bridge.
#!/bin/bash
# Create global variables
# Define Bridge Interface
br=“br0”
# Define list of TAP interfaces to be bridged,
# for example tap=“tap0 tap1 tap2”.
tap=“tap0”
# Define physical ethernet interface to be bridged
# with TAP interface(s) above.
eth=“eth1”
eth_ip=“192.168.8.174”
eth_netmask=“255.255.255.0”
eth_broadcast=“192.168.8.255”
#gw=“192.168.8.173”
...
Start the bridge script file to configure the bridge interface.
# /etc/openvpn/bridge restart
ATTENTION
Select cipher and authentication algorithms by specifying cipher and auth. To see which algorithms are
available, type:
# openvpn --show-ciphers
# openvpn --show-auths
7. Start both OpenVPN peers on machine OpenVPN A and OpenVPN B.
# openvpn --config /etc/openvpn/tap0-br.conf&
