V2416 Linux User's Manual Programming Guide
4-8
int mxhtsp_is_button_pressed (int fd, int btn_num)
Description Check if a button is pressed.
Parameters fd: the open port
btn_num: the button number
Returns 1: pressed
0: not pressed
-1: fail
int mxhtsp_is_disk_busy (int fd, int disk_num)
Description Check if a disk is busy.
Parameters fd: the open port
disk_num: the disk number
Returns 1: busy
0: idle
-1: fail
int mxhtsp_is_disk_plugged (int fd, int disk_num)
Description Check if a disk is plugged in.
Parameters fd: the open port
disk_num: the disk number
Returns 1: plugged
0: unplugged
-1: fail
Open the hotswap devices.
Description Check if a disk is plugged in.
Returns fd if successful
-1: fail
int mxhtsp_set_led (int fd, int led_num, int on)
Description Set the led to on/off.
Parameters fd: the open port
led_num: the led number
1 on
0 off
Returns 0: success
-1: fail
MDM Features
The V2416-LX computers work well with Moxa Device Manager (MDM for short), which is an easy-to-use
remote management tool for managing Moxa’s ready-to-run embedded computers over the Internet. Moxa’s
embedded computers make excellent front-end computers at remote sites for on-site data collection and
industrial control applications. MDM is designed to make it easy for system administrators to manage their
remote embedded computers. One of the key benefits of MDM is that management tasks, such as configuring
the network, managing and/or transmitting text and binary files, and monitoring and controlling processes,
can be handled easily using a Windows-based user interface. In addition, MDM can be used to manage different
models of embedded computer, and embedded computers that use different operating systems, all from one
centrally located computer. As long as the individual embedded computers are preinstalled with MDM Agent,
they can be recognized and managed by the unified MDM Client from your PC. These features help ensure that
MDM gives system integrators an efficient tool for handling all remote devices from one computer.
