V2416 Linux User's Manual Software Components
A-15
ucf 3.0016 Update Configuration File: preserve user changes to
config fil
udev 0.125-7+lenny3 /dev/ and hotplug management daemon
update-inetd 4.31 inetd configuration file updater
usbmount 0.0.14.1 automatically mount and unmount USB mass storage
devices
usbutils 0.73-10 Linux USB utilities
uswsusp 0.7-1.2
tools to use userspace software suspend provided by
Linux
util-linux 2.13.1.1-1 Miscellaneous system utilities
vbetool 1.0-3 run real-mode video BIOS code to alter hardware
state
vim 1:7.1.314-3+lenny2 Vi IMproved - enhanced vi editor
vim-common 1:7.1.314-3+lenny2 Vi IMproved - Common files
vim-runtime 1:7.1.314-3+lenny2 Vi IMproved - Runtime files
vim-tiny 1:7.1.314-3+lenny2 Vi IMproved - enhanced vi editor - compact version
w3m 0.5.2-2+b1 WWW browsable pager with excellent tables/frames
support
watchdog 5.4-10 A software watchdog
wget 1.11.4-2+lenny1 retrieves files from the web
whiptail 0.52.2-11.3+lenny1 Displays user-friendly dialog boxes from shell scripts
whois 4.7.30 an intelligent whois client
wodim 9:1.1.9-1 command line CD/DVD writing tool
x-ttcidfont-conf 31 TrueType and CID fonts configuration for X
x11-apps 7.3+4 X applications
x11-common 1:7.3+20 X Window System (X.Org) infrastructure
x11-session-utils 7.3+1 X session utilities
x11-utils 7.3+2+nmu1 X11 utilities
x11-xfs-utils 7.3+1 X font server utilities
x11-xkb-utils 7.4+1 X11 XKB utilities
x11-xserver-utils 7.3+5 X server utilities
xauth 1:1.0.3-2 X authentication utility
xbase-clients 1:7.3+20 miscellaneous X clients - metapackage
xfonts-100dpi 1:1.0.0-4 100 dpi fonts for X
xfonts-75dpi 1:1.0.0-4 75 dpi fonts for X
xfonts-base 1:1.0.0-5 standard fonts for X
xfonts-encodings 1:1.0.2-3 Encodings for X.Org fonts
xfonts-scalable 1:1.0.0-6 scalable fonts for X
xfonts-utils 1:7.4+1 X Window System font utility programs
xinit 1.0.9-2 X server initialisation tool
xkb-data 1.3-2 X Keyboard Extension (XKB) configuration data
xml-core 0.12 XML infrastructure and XML catalog file support
xorg 1:7.3+20 X.Org X Window System
xorg-docs 1:1.4-4 Miscellaneous documentation for the X.Org software
suite
xserver-xephyr 2:1.4.2-10.lenny2 nested X server
xserver-xorg 1:7.3+20 the X.Org X server
xserver-xorg-core 2:1.4.2-10.lenny2 Xorg X server - core server
xserver-xorg-input-all 1:7.3+20 the X.Org X server -- input driver metapackage
xserver-xorg-input-evdev 1:2.0.8-1 X.Org X server -- evdev input driver
xserver-xorg-input-kbd 1:1.3.1-1 X.Org X server -- keyboard input driver
xserver-xorg-input-mouse 1:1.3.0-1 X.Org X server -- mouse input driver
xserver-xorg-input-synaptic 0.14.7~git20070706-3 Synaptics TouchPad driver for X.Org/XFree86 server
