MD-124 HW Manual On-screen Display and Display Configuration

B-7

OSD Menu Items Explained

The following section explains all possible image properties that the user can encounter or adjust. The menu location of

each item is described as a filetree path. Please review the OSD Menu Map earlier in this manual for an overview of the

menu file structure. Most parameters may be adjusted in real time, so you do not need to exit the OSD menu to check

results.

Note: For custom products and/or collaborative OSD software solutions, the menu properties listed here may deviate

slightly from the OSD menu that has shipped with your product.

Basic Image Properties

Display-Picture-Brightness

This is only available in Full Menu mode.

Electronically increase/decrease the overall brightness of the panel by adjusting the voltage level.

This applies to the Main Source signal. Window overlays (PIP/PBP) and the OSD Menu overlay will be

unaffacted.

Scale is from 0-100. 50 is the default.

Display-Picture-Contrast

This is only available in Full Menu mode.

This increases/decreases the overall contrast of the panel electronically by controlling the voltage level.

This applies to the Main Source signal. Window overlays (PIP/PBP) and the OSD Menu overlay will be

unaffacted.

Scale is from 0-100. 50 is the default.

Display-Picture-Phase

This only applies to analog VGA/RGB signals. Can affect image quality.

This function will remove pixellation defects (particularly evident in black areas) that manifest as a vertical line from

top to bottom by fine tuning signal data sampling.

Scale is from 0-100. Default is relative to signal source.

Display-Picture-Frequency

This only applies to analog VGA/RGB signals.

This adjusts the horizontal frequency of the analog signal to improve visibility of the entire image. When it is

adjusted, you will notice that the image will appear to be stretched and might in some situations start to flicker/

scroll, at which point you must reverse the last adjustment to stop it from flickering/scrolling anymore. This function

can be used for older signals that is not automatically detected by the internal display controller.

Scale is from 0-200 steps. Default is relative to signal source.

Display-Picture-Sharpness

This increases/decreases the overall image sharpness. This affects the whole panel, and applies to all signal inputs

and window overlays (PIP/PBP). Use it to increase the visual quality of signals from possible older equipment or

electronically weak signals.

Scale is from 0-15 steps. 7 is default.
