MD-124 HW Manual On-screen Display and Display Configuration

B-16

Brightness, PIP Size, Main Source, Second Source, Swap Source, Test Pattern. The assignment No

Function eliminates all hotkey assignments for the right/left arrows, leaving them (per default) only effective when

the OSD Menu is activated.

When selected, a box icon (█) will indicate that the selected function has been activated.

Display Setup: Service Menu

Display-Setup-Service Menu-Type and Serial

This is only available in Full Menu mode.

This menu item reports the display unit’s model and serial number. This information is stored electronically,

on-board. Example: MD-124ABCD12345678: the model number forms the first five numbers, and the remaining

digits form the serial number.

Display-Setup-Service Menu-Firmware Ver

This is only available in Full Menu mode.

This menu item reports the device’s firmware version. Firmware updates may only be undertaken by a Moxa

engineer. If a firmware revision or customization is required, please contact Moxa’s customer support to learn about

our Professional Design Service (PDS).

Example: “V.10”.

Display-Setup-Service Menu-Elapsed Time (hr)

This is only available in Full Menu mode.

This function reports the total hours the display panel has been running since it was first installed; this is not the

same as how long the display has been powered up: the total time spent displaying an image since installation is

reported, and only time spent actually displaying an image is included. With reference to the device’s MTBF, this

menu item may be used to calculate the remaining life span of the device.

As an example, if the number 452 is displayed, here, then the device has been displaying images for a total of 452

hours.

Display-Setup-Service Menu-Fault Status

This is only available in Full Menu mode.

This function will show the last recorded fault message detected by the display controller.

As an example, if the phrase Fan Status is displayed, here, then the last device error recorded by the system log

is the fan’s operating status.

Display: Input Sources / Dual Image Displays

Display-Source-Single-xxx

This menu item allows users to configure the display to display a single, solitary source input, without any

picture-in-a-picture or picture-by-a-picture configuration.

After navigating to Display/Source, upon selecting Single from the menu offered you will be transferred to a

submenu from which you may then select which signal source should be configured as the sole input signal to be

displayed. A small, square icon ( █ ) will appear next to whichever menu item is selected to indicate the currently

configured signal source.

Whichever source is selected as the single display will automatically be configured as the Main Source. This means

that, should the Swap Source feature be selected, the input source configured through the
