MD-124 HW Manual Introduction

1-2

Overview

The MD-124 Series has been designed to fit the peculiar environmental demands of maritime industrial

systems. The 24-inch panel features a 16:9 aspect ratio and a 1920 x 1080 pixel resolution, making this display

ideal for any marine application requiring detailed, high-resolution imagery. In addition, with full range

dimming, optical bonding (Y models only), and designed with 2D, 178° wide angle viewing, these computer

display terminals satisfy a variety of international maritime standards.

Package Checklist

The MD-124 Series includes the following models:

MD-124X: 24-inch marine display with 16:9 aspect ratio, full HD resolution (1920x1080), LED backlighting,

multiple input AC/DC power supply, and tape bonding

MD-124Y: 24-inch marine display with 16:9 aspect ratio, full HD resolution (1920x1080), LED backlighting,

multiple input AC/DC power supply, and optical bonding

MD-124Z: 24-inch touch-screen display with 16:9 aspect ratio, full HD resolution (1920x1080), LED

backlighting, and a multiple input AC/DC power supply

Each model ships with the following items:

• MD-124 display

• Rubber waterproofing cushion

• DVI to VGA adapter

• VGA Cable

• DVI-D Cable

• Console Mounting Kit

• MD-124-Z only: USB cable for Touch-screen capability

• Terminal block for DC power in

• DC Terminal block for the buzzer

• Documentation and driver CD

• Quick installation guide (printed)

• Warranty card

NOTE

Please notify your sales representative if any of

the above items are missing or damaged.

Product Features

The MD-124 display has the following features:

• 24-inch wide viewable image size with 16:9 aspect ratio and 1920 x 1080 pixel resolution

• LED backlighting

• Optical bonding (Y model)

• Surface capacity touch (Z model)

• ECDIS color calibration model available (by request)

• PIP/PBP

• Multi-power input (24 VDC, 110 to 230 VAC)

• IP66 rated front panel
