MD-124 HW Manual On-screen Display and Display Configuration

B-13

important information on the display must be visible at all times. A black border around the OSD menu layout will

always be black and is not affected by this adjustment.

Scale is from 0-100. 50 is the default.

Display-Setup-OSD Settings-OSD Horz Position

Moves the horizontal (left/right) position of the OSD Menu. The OSD can only be moved within the available display

area.

Scale is from 0-100. 100 is default.

Display-Setup-OSD Settings-OSD Vert Position

Move the vertical (left/right) position of the OSD Menu overlay. The OSD can only be moved within the available

display area.

Scale is from 0-100. 100 is default.

Display-Setup-OSD Settings-Full Menu

This is only available after the administrator password has been entered.

If the Simplified OSD mode is insufficient for your purposes, you may gain access to all possible display

parameters by following this procedure:

• Press the right arrow (►) to activate this function

• A data entry dialog will appear, with 3 digits shown, each defaulting to zero (0 0 0).

• To enable Full Menu mode, change the 3 digits to 158, then

• Press the right arrow (►) to confirm.

Now all menu functions will be accessible. When you power off the product, this setting will revert back to

Simplified mode.

Note: To force the OSD Menu to always appear in full menu mode, you must first unlock the OSD Menu with the

procedure as described and then navigate the OSD menu to Display-Setup-OSD Settings-OSD Mode-Full

where you may activate the Full Menu setting as default.

Display-Setup-OSD Settings-OSD Mode-Simplified

Simplified Mode is the factory default.

This setting only appears when the display is in Full Menu

mode.

This selection forces the OSD Menu to always appear in Simplified Mode (even after power shutdown of the unit).

This means that a lot of advanced functions will not be accessible from the OSD menu. Setting the OSD to simplified

mode is to prevent advanced changes to the display that could profoundly affect display functionality and/or image

quality. Only experienced and qualified personnel should access and change this setting.

When selected, a box icon (█) will indicate that the selected function has been activated.

Display-Setup-OSD Settings-OSD Mode-Full

This is only available in Full Menu mode.

Force the OSD Menu to always appear in Full Menu mode (even when powering on after a shutdown of the unit).

This means that all possible display functions will be accessible from the OSD Menu.

Only experienced and qualified personnel should access and change this setting.

When selected, a box icon (█) will indicate that the selected function has been activated.
