Moxa MD-124Y [29/33] Display setup user settings

MD-124 HW Manual On-screen Display and Display Configuration

B-14

Display-Setup-OSD Settings-Lock Mode-Normal

This is only available in Full Menu mode.

This unlocks the OSD Menu so that users may access it without any password protection.

When selected, a box icon (█) will indicate that the selected function has been activated.

Display-Setup-OSD Settings-Lock Mode-Password Protect

This is only available in Full Menu mode.

When the OSD Menu is set to Password Protect, users will need to enter a password before access to the OSD

Menu (image properties dialog) is granted.

When Password Protect is set, any user who presses MENU will first be directed to a password entry dialog, which

will display 3 zeroes as default (0 0 0).

To enter the OSD Menu, use the up and down arrows to input 321 and then press the right arrow (►) to confirm.

Password protection will remain active even after powering down; to gain access, the same password will continue

to be required until Display-Setup-OSD Settings-Lock Mode-Normal is reset.

When selected, a box icon (█) will indicate that the selected function has been activated.

Display Setup: User Settings

Display-Setup-User Settings-DPMS

This enables/disables the VESA Display Power Management Signaling (DPMS) function. DPMS is a standard

established by the VESA Consortium that enables intelligent power management of computer display units via the

graphics card. DPMS allows the panel to save power by decreasing or cutting off power after the display has sat idle

for a specified period of time. The default setting is Enable DPMS (On).

When selected, a box icon (█) will indicate that the selected function has been activated.

Display-Setup-User Settings-Communication-RS-232

This is only available in Full Menu mode.

This item sets the built-in serial port to the RS-232 protocol, enabling serial communications control via an RS-232

interface; i.e., the MD-124 may use the serial port to serve as the DTE of a remote DCE.

This setting enables operators to modify a wide range of the display controller’s internal parameters. Daisy-chain

operation is also possible if the DCE is equipped with a second COM port.

When selected, a box icon (█) will indicate that the selected function has been activated.

Display-Setup-User Settings-Communication-2-wire RS-485

This is only available in Full Menu mode.

This setting configures the built-in serial port as a 2 wire RS-485 interface, enabling control serial devices over an

RS-485 serial network.

When selected, a box icon (█) will indicate that the selected function has been activated.

Display-Setup-User Settings-Communication-4-wire RS-485/RS-422

This is only available in Full Menu mode.

This setting configures the built-in serial port as a 4 wire RS-485 interface, enabling control of serial devices over an

RS-485 serial network.

When selected, a box icon (█) will indicate that the selected function has been activated.
