Moxa TCC-120I [11/18] Led indicators
![Moxa TCC-120I [11/18] Led indicators](/views2/1200759/page11/bgb.png)
7
LED Indicators
The TCC-120/120I’s top panel contains three LED indicators, as described in
the table below:
LED Name
LED Function
PWR
Red indicates the power is on.
Orange
Data is entering through the top-end port and
exiting through the bottom-end port.
Green
Data is entering through the bottom-end port
and exiting through the top-end port.
