ioLogik E1500 Series Initial Setup
2-2
Hardware Installation
Connecting the Power
Connect the 12 to 48 VDC power line to the terminal block on the top panel of the ioLogik E1500. If power is
properly supplied, the Power LED will glow a solid amber color.
ATTENTION
•
Disconnect the power cord before installing or wiring your ioLogik E1500.
•
Do not exceed the maximum current for the wiring
•
Determine the maximum possible current for each power wire and common wire. Observe all electrical
codes dictating the maximum current allowable for each wire size. If the current exceeds the maximum
rating, the wiring could overheat, causing serious damage to your equipment. For safety reasons, we
recommend an average cable size of 22 AWG. However, depending on the current load, you may want to
adjust your cable size (the maximum wire size for power connectors is 2 mm).
Grounding the ioLogik E1500
The ioLogik E1500 is equipped with a grounding point on the terminal block located on the top panel. Connect
the ground pin ( ) if earth ground is available.
Connecting to the Network
The ioLogik E1500 uses an M12-to-RJ45 Cat 5e UTP Ethernet cable for connecting to either the host PC or
another ioLogik device. The M12 connector ensures a tight, robust connection, and guarantees reliable
operations even for applications that are subject to high vibration and shock.
For initial setup of the ioLogik E1500, it is recommended that the ioLogik E1500 be configured using a direct
connection to a host computer rather than remotely over the network.
Configure the host PC’s IP address to 192.168.127.xxx (where xxx ranges from 001 to 253). When using
Windows, you will need to do the configuration from the Control Panel.
ioLogik E1500 Default IP Address Default Netmask Default Gateway
192.168.127.254 255.255.255.0 None
Use the web console or ioSearch configuration utility to connect to the ioLogik E1500. Once the ioLogik E1500
has been detected, modify the settings as needed for your network environment, and then restart the server.
Refer to Chapters 3 and 4 or further details.
