Moxa C Programmable RTU Controllers Getting Started
2-5
Removing ioPAC 8020-C Series from the DIN-Rail
To remove the ioPAC 8020-C from the DIN-rail, use a screwdriver to push down the spring-loaded bracket until
it locks in place, as shown in the diagram to the right. Next, rotate the bottom of the switch upwards and then
remove the switch from the DIN-rail.
ioLogik W5348-C Series
STEP 1: Insert the top of the DIN-rail into the slot just below the stiff metal spring.
STEP 2: The DIN-rail attachment unit will snap into place as shown below.
To remove the ioLogik unit from the DIN-rail, simply reverse Steps 1 and 2 above.
