Moxa VPort 26A-1MP Introduction

1-10

The VPort 26A

1MP supports a standard SDHC interface. Users can use SD cards suitable for this specification.

Transcend or Sandisk SD cards are recommended, particularly Sandisk Extreme III SD, because of their rapid

read/write speed.

NOTE

To check if the SD card has been successfully mounted, access the VPort’s web

-based manager and check

under system configuration

-> Local storage.

Reset Button

The reset button is used to reset the camera hardware.

1. Reboot:

To reboot the VPort 26A-1MP, power it off and then power it back on again, or push the RESET button one time.

The System LED will light in red as the POST (Power on Self Test) process runs. When the rebooting process is

finished, the System LED will change to a green color.

2. Restore to Factory Settings:

To restore the VPort 26A-1MP to the factory default settings, press the reset button continuously until the

System LED blinks in red. After the system LED stops blinking, release the reset button. The POST process will

run, and the VPort will reboot. The System LED will light in green when the VPort has finished rebooting.

RJ45 Ethernet Port

The RJ45 Ethernet port is for 10/100Mbps network transmission, in addition to PoE (power over Ethernet,

802.3af) power supply for VPort P26A.

NOTE

The VPort P26 supports standard IEEE 802.3af Power

-over-Ethernet (PoE). T

he maximum power consumption

is about

5.8W.

NOTE

The equipment is designed for in building installation only and is not intended to be connected to exposed

(outside

plant) networks.
