![Moxa VPort P26A-1MP-T [9/82] Product features](/views2/1201823/page9/bg9.png)
Moxa VPort 26A-1MP Introduction
1-5
Product Features
High Video Image Quality
• 1/2.7” progressive CMOS sensor for HD (1280 x 720) resolution
• Day and night viewing capability with ICR (IR cut filter) and color /black & white image switch
• Supports DNR (digital noise reduction), BLC (back level control), and WDR (wide dynamic range) for better
image quality
• Equipped with 3 mm to 9 mm vari-focal megapixel lens for wide-range fields of view
• Minimum illumination up to 0.2 lux (color) and 0.05 lux (B/W) at F=1.2
• Image mirror and inverse
• 350° pan, 85° tilt, and 360° rotate camera head angles for different installation positions.
• Supports up to 3 privacy mask areas and 4X digital zoom
Excellent Video/Audio streaming and network transmission performance
• Up to 3 simultaneous video streams for H.264 and MJPEG codecs
• Video stream up to 30 frames/sec at WXGA (1280 x 800) resolution
• DynaStream™ supported for optimal network efficiency
• CBR Pro™ supported for high image quality in limited bandwidth transmissions
• Video latency under 200 ms
• 1 audio input and 1 audio output supported for complete video/audio surveillance solution
• WXGA/HD/SVGA/Full D1/ 4CIF/ VGA/ CIF/ QCIF resolution
• TCP, UDP, and HTTP network transmission mode
• Supports RTSP streaming
• Supports IGMP (ver.3) protocols for efficient network transmission
• Supports SNMP (V1/V2C/V3) for network system integration and management
• Supports QoS (ToS) for transmission priority
• Adjustable frame rate and bit rate control
• User-friendly IP filtering
• Supports IEEE802.1X for network access authentications
• Supports HTTPS and SSH for network transmission security
• UPnP Supported
• Up to 5 unicast video streams, and 50 multicast clients
• Supports multicast push for all multicast clients
• OnVIF standard supported for compatibility with other IP video products
• Modbus/TCP supported for direct communication with SCADA system
Rugged Design for Mission-critical Industrial Environments
• IP66 form factor protection for rain and dust
• Model available with PoE (802.3af) or 12/24 VDC and 24 VAC power input, with LED indicators
• Panel mounting for mounting on a ceiling, or outdoor installation kit for versatile installation method
• -40 to 50°C or -40 to 75°C (T model) operating temperature for critical industrial environments
• No heater or fan for long MTBF
• CE, FCC, UL60950-1
• 5-year product warranty
Intelligent Alarm Triggering Capability
• Built-in tamper alarm, and VMD (video motion detection)
• 1 DI and 1 relay output (DO) for sensors and alarms
• Supports video loss alarm
• Pre, trigger, and post snapshot images supported
