VP-022D Getting Started

2-18

PTZ Camera Configurations

Select PTZ in the left panel to enter the settings page for PTZ cameras.

General

Transfer Mode: Fixed in ONVIF mode

RS-485 protocol: No specified protocol

Control Panel: Fixed in Joystick

Transparent Port: The VP-022D supports the transparent PTZ control function, which means the user can

connect a legacy PTZ control panel to the VP-022D’s RJ-45 port to control the PTZ camera connected to the

VPort video encoder. It is not necessary to install the PTZs driver.

NOTE

To enable the transparent PTZ control function, the PTZ driver in

the

VPort series video encoders should be set

to Transparent PTZ Control.

For the port setting, please refer to below parameters:

Baud rate (bps) 9600

Data bits 8

Stop bits 1

Parity bits None
