VPort 364A System Configuration
5-35
Setting Description Default
Enable VMD alarm Enable or disable the Video Motion Detection alarm Disabled
Show alert on the
image when VMD is
triggered
Enable or disable the “show the alert,” which when enabled
displays a red square frame on the video image of the VMD
alarm notification
Disabled
Channel Selection Select Channel 1, 2, 3, or 4 to setup the VMD alarm Channel 1
