VPort 364A Introduction

2-4

• Supports H.264/MJPEG video compression technologies

• Dual simultaneous video streams (1 H.264 and 1 MJPEG).

• Lower latency, under 200 ms.

• 4 BNC video inputs

• Single video stream up to 30 frames/sec in Full D1 (720 x 48resolution in NTSC, and 25 frames/ sec in Full

D1 (720 x 576) resolution in PAL

• Select from Full D1/ 4CIF/ VGA/ CIF/ QCIF resolutions.

• 1 audio input and 1 audio output for 2-way voice communication

• TCP, UDP, and HTTP network transmission modes

• Supports Modbus/TCP for easy communication with SCADA systems

• Standard RTSP (Real-time streaming protocol) for easy integration

• DynaStream™ for automatic frame rate adjustment

• Supports multicast (IGMP) protocols for efficient network transmission;

• DDNS, UPnP and IP filtering supported

• Supports QoS (TOS) for priority transmission

• Supports SNMP V1/V2c/V3 for network management

• Built-in web server and RS-232 console for remote access and configuration

• One auto-sensing 10/100BaseT(X) or 100BaseFX (SC connector)Ethernet port

• 8 output video streams and 8 client connections.

• 50 multicast clients for receiving multicast video streams

• Multicast push for all the clients

• Supports CBR (constant bit rate) or VBR (variable bit rate) encoding

• Supports 1 RS-232/RS-422/RS-485 5-pin PTZ port for controlling a PTZ (PAN/TILT/ZOOM) motorized

camera via a TCP/IP network

Rugged Industrial Design

• Two 12/24 VDC and 24 VAC redundant power inputs with LED indicators

• -40 to 75°C operating temperature for critical industrial environments (“-T”models)

• 35 mm DIN-Rail mounting or panel mounting installation (requires optional accessories)

• IP30 protection form factor

• CE, FCC, and UL508 (pending) certification for industrial applications

Intelligent Alarm Trigger

• Supports system alarms, including power failure and network link

• Supports event alarms, including video motion detection (VMD),video loss, digital input, and CGI event

• Equipped with 4 DIs and 2 relays (DO) for external sensors and alarms

• Snapshot images provided for pre, trigger, and post alarm

• Sequential snapshot images supported

• Messages with snapshot images can be sent via FTP or Email

• HTTP Action setting for alarm messages sent by HTTP event server

• Capable of setting an alarm schedule

Video Management and Control

• Support for Moxa SoftNVR-IA IP surveillance software, a video recording and management solution

• Free Moxa VPORT SDK PLUS supported with flexible interface and sample code for customized applications

or system integration

NOTE

If you are interested in SoftNVR

IA IP surveillance software, please go to Moxa’s website www.moxa.com to

download the trial version

NOTE

If you are interested in Moxa’s VPortSDK PLUS, please go to Moxa’s website www.moxa.com to download the

package, or contact a Moxa sales representative for more information about this SDK
