Moxa MxNVR-IA8 Technical Specifications
D-2
Video 1/2/3/4/5/6/7/8 The status of video channel 1 to 8
LAN 10/100/1000 Mbps Ethernet link status
Power
Input Voltage 1 24 VDC power input with the 3-pin terminal block connector
Power Consumption Max. of 20 watts (with 2 2.5” 500GB hard disk)
Physical Characteristics
Housing Metal
Dimensions (W x H x D) 440 x 44 x 325 mm (17.32 x 1.73 x 12.8 in)
Weight Appro. 3.6 Kg
Installation 19” rackmount
Security
Password User level password protection
Filtering By IP address
Authentication 802.1X
Environmental Limits
Operating Temperature
Standard models: 0 to 60°C (32 to 140°F)
Wide Temp. models: -40 to 75°C (-40 to 167°F)
Storage Temperature -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity 5 to 95% (non-condensing)
Regulatory Approvals
Safety UL 60950-1
EMI FCC Part 15 Subpart B Class A, EN55022 class A
EMS
EN61000-4-2 (ESD), Level 3
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 2
EN61000-4-5 (Surge), Level 3
EN61000-4-6 (CS), Level 3
EN61000-4-8
EN61000-4-11
Shock IEC60068-2-27
Freefall IEC60068-2-32
Vibration IEC60068-2-6
Warranty
Warranty period 5 years
Details See www.moxa.com/warranty
System Requirements
CPU Pentiun 4 2.4 GHz or above
Memory 512 MB memory or above
OS Windows XP/2000 with SP2 or above
Browser Internet Explore 6.x or above
Multimedia DirectX9.0C or above
Software development kit
VPort SDK PLUS
Includes VPort CGI commands, ActiveX Control, and API library for
customized applications or system integration for third-
party developers
(the latest version or SDK is available for download from Moxa’s website )
