User Manual User Manual

IR-T2 CONDTROLIR-T2 CONDTROL

INFRARED THERMOMETER

SPECIFICATIONS

Optical Resolution 10:1

Temperature range -30 to 315°C (-22 to 600°F)

Accuracy -40 to 10°C: ±3°C

10 to 30°C: ±1°C

Above 30°C: ±1.5°C or ±2%

whichever is greater

Distance for measurement 50mm to 400mm

Display Resolution 0.1 °C/°F

Display Unit °C/°F (default unit = °C)

Emissivity Pre-set 0.95

RH Display Range: 20% to 90%

(Accuracy +/- 5%)

Ambient / Dew Temp Display Dew Point (Range: -20°C to 60°C)

Dew Bar Display Yes

MIN/MAX/AVG Display Yes

Laser Class II < 1 mW, 630-670 nm

Operating temperature 0 °С to +60°С

Storage temperature -10 °С to +70°С

Auto Shutoff 1st Level 20 seconds after turn-on

Auto Shutoff 2nd Level 2 minutes without usage

MECHANICAL

1. Drop Test : The product should withstand and be functional with only

minor dents, abrasions and cracks after 3 random drops of 3 feet high onto

cement surface

2. Button Life Test : On/Off switch will be actuated 50,000 times with no

failure allowable

3. Slide Switch Button Life Test : C/F adjustment will be actuated 1,000 times

with no failure allowable

4. Battery Door Life Test : Open / Close Battery Door will be actuated 1,000

times with no failure allowable.

5. Housing is ABS with Rubber Handle and Lens is PC for the outside plastic

part

Key Description

1. Activation Trigger: Press to measure the Surface temperature, Ambient

Temperature & Relative Humidity.

2. Min/Max/Avg: Press to show the min, max or average of the surface

temperature, and enter to Emmisivity setting mode and Atemp/Dtemp

setting mode.

3. C/F(Switch) To select the unit of temperature.
