User Manual User Manual

IR-T2 CONDTROLIR-T2 CONDTROL

INFRARED THERMOMETER

ATEMP/DTEMP SETTING MODE

1. Press “Max/Min/Avg” key again after Emissivity mode, it reaches the

Atemp/Dtemp setting mode.

2. Press Activation Trigger to change the display of Atemp or Dtemp.

3. Press “Max/Min/Avg” key or wait for exit from setting mode to confirm

the selection.

Celsius and Fahrenheit

1. Users can change the temperature unit from Celsius to Fahrenheit and

vise versa by sliding the C/F switch.

LOW BATTERY

1. If the unit is low in battery power,

the LCD flashes the battery icon on

the top left corner.

2. If the unit is almost out of power,

the “BAT” will show on the LCD

display.

Flashing

Toggle with trigger button

DEW POINT LEVEL

1. The bar on the left indicates the degree of occurrence of fog or dew on

surface material being scanned. E.g. if the surface temperature is below that

of the Dew Point, the bar shows full segments showing fog or dew can occur.

2. If the surface temperature is 2.5 degrees below Dew Point, the bar on the

left displays 10 segments.

3. If the surface temperature is same as Dew Point, the bar on the left

displays 5 segment.

4. If the surface temperature is 2.5 degrees above Dew Point, the bar is left

blank showing no fog or dew occurs.

Surface temperature

is 2.5 degree

below Dew point

Surface temperature

is same as Dew point

Surface temperature

is 2.5 degree

above Dew point
