Bosch BSGL 52530 [9/100] Vacuuming

Bosch BSGL 52530 [9/100] Vacuuming
8
Figure
● Push the telescopic tube into the connecting piece
on the floor tool until it locks in place.
● To release the connection, press the locking collar
a
nd pull out the telescopic tube.
Figure
● Move the sliding sleeve in the direction of the arrow
to release the telescopic tube and adjust it to the
length required.
Figure
● Holding the power cord by the plug, pull out the
required length and plug the plug into the mains
socket.
Figure Switching on and off
● To switch the vacuum cleaner on or off, press the
ON/OFF button.
Figure Controlling the suction level
The required suction level can be set to the level
required by turning the control knob in the direction
of the arrow.
Low power range =>
For vacuuming delicate
materials, e.g. curtains.
Medium power range =>
For the daily vacuuming of light
dirt deposits.
High power range =>
For cleaning durable floor coverings, hard
floors and heavy dirt deposits.
Vacuuming
!
Please note:
Floor tools are subject to a certain amount of wear,
depending on the type of hard floor you have (e.g.
rough, rustic tiles). Therefore, you must check the
underside of the floor tool at regular intervals. Worn
undersides of floor tools may have sharp edges that
can damage sensitive hard floors, such as parquet or
linoleum. The manufacturer does not accept any
responsibility for damage caused by worn floor tools.
Figure
Adjusting the floor tool:
Rugs and carpets =>
hard floors =>
Figure
●Remove the crevice nozzle or upholstery nozzle from
the accessories compartment in the appliance lid.
5*
6*
7
8
9
10
11
Figure Vacuuming with accessories
Attach the nozzles to the suction pipe or handgrip as
required:
a)Crevice nozzle for vacuuming crevices and corners,
e
tc.
b)Upholstery nozzle for vacuuming upholstered
furniture, curtains, etc.
c)Hard floor tool
For vacuuming hard floor coverings
(tiles, parquet flooring, etc.)
●
Push the telescopic tube into the connecting piece
of the hard floor tool until it locks in place.
● To release the connection, press the locking collar
and pull out the telescopic tube.
Figure
● After use, place the crevice or upholstery nozzle back
into the accessories compartment in the appliance
lid.
Turbo brush
If your appliance is equipped with a turbo brush,
please consult the accompanying instruction manual
for in-structions on its use and maintenance.
Figure
● You can use the nozzle parking aid on the back of the
appliance if you wish to stop vacuuming for a short
time.
● Once you have switched off the appliance, slide the
hook on the floor tool into the recess on the rear of
the appliance.
Figure
To overcome obstacles, e.g. steps, the appliance can
also be carried by the handle on the appliance body.
When the work is done
Figure
● Pull out the mains plug.
● Tug the power cord briefly and then let go (the
power cord retracts automatically).
Figure
● To store or transport the appliance, you can use the
storage aid on the underside of the appliance.
●Stand the appliance up on its end. Slide the catch on
the floor tool into the groove on the underside of the
appliance.
12*
13
14
15
16
17
*
depending on model
