21
Operation of additional equipment
Calling an AV program in the AV selection list
Call AV selection list
Select AV connection (e.g. socket
AV1) or VIDEO for the VCR
station.
Now you will see the playback from the
connected AV unit.
Calling an AV in the station table
Call the station table
In the numeric sorting you will always find the AV
devices at the top of the list without station
numbers.
Select the AV connection and...
confirm with OK.
Now you will see the playback from the
connected AV unit.
Video playback
In order to see the VCR picture on your TV and
hear its sound you have several possibilities:
1. You can use the Euro-AV sockets on the TV set
and on the VCR. This is the best option of all -
good picture and sound quality.
If you are playing back from a VCR with Digital
Link Plus, the VCR picture is shown on the
current station slot.
If you are playing back from a standard VCR,
DVD player or camcorder, select the AV socket to
which the video signal is connected in the AV
selection list or the station table.
Video recorders emit a switching voltage during
playback which the TV set can decode (can be
activated for every VCR in the connection wizard
or set Settings - AV Settings - Allow switching
voltage to "Yes" in the TV menu). Then the VCR
picture is shown on the current station slot as in
Digital Link Plus VCR's.
2. You can also control logged-in Loewe VCRs
and DVD players with the video menu bar. See
page 19 for more details.
3. Use the antenna connection between the VCR
and the TV. The sound is only transmitted in
mono. Select the first menu item, e.g. VIDEO, in
the AV selection.
Channel overview: TV Numerical
AVS
AV3
AV2
AV1
0 VIDEO
1 ARD
2 ZDF
3 SAT.1
4 RTL
5 VOX
6 S–RTL
7 N–TV
8 DSF
9 TM3
10 PRO7
11 RTL 2
12 WDR 3
13 BR 3
14 HR
15 MDR 3
0 9
Select and
press OK to proceed
Menu
Info
End
Change sorting
Change programs
DR archive
Favourite programs
... Select program:
OK
INFO
MENU
END
AV
OK
OK
OK
VIDEO AV1 AV2 AV3 AVS VGA/XGA DVI COMP.IN
AV Selection
IR-Link
Your TV set is equipped with the IR-Link socket
(IR Link), a cable with plug and the IR
transmitter diode are included with the set.
This allows you to operate a concealed d-box or
a VCR from another manufacturer with its
remote control through the TV set with most
remote controls. Plug the jack plug of the cable
with infrared transmitting diode into the IR
socket on the back of the TV. The infrared
transmitting diode at the end of this cable must
be placed in front of the concealed device. The
TV must be switched on for transmission.
A napped strip is provided to help to lay the
cable. The strip is self-adhesive; pull off the
backing foil first. Stick the strip to the shelf or
cabinet and press the cable into the naps. You
can cut up the strip into several sections with a
knife.
Point the infrared remote control at the TV to
operate the concealed VCR.
HMM (Home Multi Media)
The following menu items are only required
when an "OnlinePlus Module" is integrated.
The Home Multi Media function (HMM) must
be activated on the remote control for this
(> Mode RC Setup<).
HMM on/off
Switch the Home Multi Media mode on/off.
HMM sound
Play the sound of the built-in HMM module.
HMM window
Switch over pages when several Internet pages
are displayed at the same time.
OK
31599_021_Articos55_GB_(ro) 24.03.2004, 13:28 Uhr21
