8
Batteries
To insert or change the batteries, press the
point marked by an embossed arrow. Push the
cover of the battery compartment down and
remove it. Insert the batteries of the alkaline
manganese type LR 03 (AAA) with the correct
polarity (+/-).
Then push the cover back on.
If you are inserting batteries in the remote
control for the first time or changing the
batteries you will see the language selection
for the remote control in the display. Select
German or English with the rocker. Press the
SET button to confirm your selection. The
display shows the "TV" menu, the remote
control is set for operating the TV.
Note on disposal of batteries:
The original batteries do not
contain any pollutants such as
cadmium, lead and mercury.
Used batteries do not belong in
the domestic waste. They must
be taken to the appropriate
collection points according to
the national laws. Ask your
dealer.
Initial installation
Connection
Mains
Connect the TV set to a 230V/50-60 Hertz
outlet.
Antenna
Connect your antenna or cable system to the
antenna socket to the UHF/VHF antenna socket
on the back of the set.
When equipped with a DVB-T module, connect
your antenna system to the top socket of the
DVB-T module (IN) and connect the bottom
socket (OUT) to the antenna input of the PIP
tuner.
When equipped with a satellite tuner, connect
the satellite antenna to the SAT sockets.
Switching on
Press the On/Off button so that it is pressed in.
Note:
• Due to the optical back projection system it
takes about 30 seconds for the picture to
appear on the screen after switching on.
Full brightness is not reached until after 2
minutes.
• Due to the DMD technology used, up to four
black pixels may appear on the screen.
•Frequent switching on and off affects the
life of the built-in projection lamp.
Initial installation
Automatic programming of the TV set is started
the first time you switch it on. Follow the
menus.
First you have to select the menu language for
your set. Then you specify which antenna you
have connected to your TV and in what country
you are using it. Then you start the station
search. The TV set searches for, stores and sorts
all the stations which your antenna system
receives. You then see a list of the stored
stations in which you can mark your favorites.
Finally log in your video recorders, decoders,
Loewe audio system and Home Automation
with the connection wizard and connect these
to the TV set according to the illustrated
connection plan.
Select the settings with the
arrows on the ring ...
... confirm the settings with
OK. You then move on to the
next menu ...
... press this button if you want
information about the settings.
You can repeat initial installation at any time,
e.g. after moving house. Call the index in the
main information (i button). Then select the
item "Repeat initial installation". Then start
"Initial installation" with OK.
SUB
AV 2
(RGB)
D
V
I
C
R
L
S
U
R
AV 1
AV 3
(RGB/YUV
)
C
R
T
L
SYSTEM
R
C
5/
RC
6
IR
-
LIN
K
SER
VICE
AU
DIO
IN 1
C
O
M
PO
N
EN
T
IN
1
IN
2
D
I
G
IT
A
L
AUDIO IN 3
R
L
R
L
R
L
A
U
D
I
O
O
U
T
OUT
Y
CR
/
PR
C
B
/
P
B
A
U
D
I
O
I
N
2
P
IP
U
HF
/V
H
F
➜
TV
OK
OK
+
++
31599_021_Articos55_GB_(ro) 24.03.2004, 13:28 Uhr8
