![Netgear R6300 [34/127] Setup menu](/views2/1205509/page34/bg22.png)
genie Advanced Home
34
R6300 WiFi Router 802.11ac Dual Band Gigabit
Within 2 minutes, go to the client device and use its WPS software to join the network
without entering a password.
The router attempts to add the WPS-capable device. The WPS LED on the front of
the router blinks green. When the router establishes a WPS connection, the LED is solid
green, and the router WPS screen displays a confirmation message.
4. Repeat Step 2 and Step 3 to add another WPS client to your network.
Setup Menu
Select Advanced > Setup to display the Setup menu. The following selections are available:
• Internet Setup. Go to the same Internet Setup screen that you can access from the
dashboard on the Basic Home screen. See Internet Setup on page 20.
• Wireless Setup. Go to the same Wireless Setup screen that you can access from the
dashboard on the Basic Home screen. See
Basic Wireless Settings on page 26.
• Guest Network. This is a shortcut to the same Guest Network screen that you can
access from the dashboard on the Basic Home screen. See Guest Networks
on page 28.
• WAN Setup. Internet (WAN) setup. See W
AN Setup on page 35.
• LAN Setup. Local area network (LAN) setup. See LAN Setup on page 38.
• QoS Setup. Quality of Service (QoS) setup. See Quality of Service (QoS) Setup on
page 41.
