APPENDIX
A.1
Printer Specifications
Item
Specification and Description
Print Speed
12 PPM
Resolution
1200 dpi image quality
First Printing Time
WarmUp Time
Less than 13 seconds
Power Consumption
250 W average during operation / Less than 10 W in sleep mode
Power Rating
AC 100 ~ 127 V (USA, Canada) / 220 ~ 240 V (Others), 50 / 60 Hz
Acoustic Noise
Stand by: Less than 35 dB; Operating: Less than 47 dB
Toner Supply
Single cartridge
Toner Cartridge Life
3,000 pages (for starter, 3,000 pages), 5% area coverage
Emulation
PCL 6
Random Access
Memory (RAM)
Standard 4 MB (expandable up to 68 MB)
: 72 pin, EDO, non-parity, 60nS;
4MB, 8MB, 16MB, 32MB or 64MB available
30 seconds
Interface
•
12PPM (A4) Bidirectional Parallel Standard
- Modes supported: Compatible, Nibble, Byte, ECP
•
USB Interface Standard
- USB 1.0 compliant
- 12Mbps 1 port
Weight
6.5 Kg / 13.4 lb.
External Dimensions
(W x D x H)
329 x 348 x 224 mm / 13 x 13.7 x 8.8 in.
Temperature:10 ~ 32 °C / 50 ~ 90 °F; Humidity: 20 ~ 80 % RH
Package Weight
Paper: 1.83 Kg
Plastic: 0.33 Kg
Duty Cycle
Monthly: 12,000 pages maximum
Operating Environment
Interface Switching
Automatic (Parallel, USB)
Fonts
1 bitmap, 45 scalable
