ProKeys 88sx User Guide

English

2.11.2 Data Entry

Some of the Advanced Functions require data entry. When in Edit mode, you can use keys F3 to B4 for data entry. Pressing ENTER will select the

data value you have entered and your ProKeys 88sx will return to Performance mode. Alternatively you can press CANCEL, which will return your

ProKeys 88sx to Performance mode and ignore any entries you may have made.

The following tables define Advanced Functions that require data entry, and the range of the data you can enter:

Key Advanced Function Data Range

If you enter a value that is out of range for the Advanced Function you have selected to edit, the last two digits you entered will be used as the

assigned value if you press Enter to confirm. For example, if you are editing the Wheel Assign value and you enter 135, the value 35 will be accepted

if you then press enter.

Default

The Default key (F3) is a data entry key that sets the parameter you are editing back to its default value, which is the value that the parameter has at

power up. The default key also has the effect of immediately returning the ProKeys 88sx back to Performance mode.

2.11.3 Enter Keys

The Enter key is located at the end of the data entry keys, key C5. When the Enter key is pressed, Performance mode resumes. Any parameter

selected for editing will be updated with any valid data values entered on the data entry keys. If Enter is pressed without having entered a data

value, the parameter remains unchanged.

< Press the Slider Assign function key, key A#3 (see Appendix B).

< Use the white data entry keys, F2 to A3 to enter the number of the Bank LSB or MSB message you want to send.

< Press C5 to accept the value and return to Performance Mode.

The Volume slider can be assigned a controller number from 0 to 131. Please see appendix C for more detail.

Note: pressing the Default key during data entry will cause the slider to become assigned to Master Volume.

2.11.6 Pedal Assign

To assign the Expression pedal to a different MIDI Controller message:

< Press the Advanced Functions button.

< Press the Pedal Assign function key, key G#3 (see Appendix B).

< Use the white data entry keys, F3 to B4 to enter the number of the controller you wish to assign to the pedal (see appendix C).

< Press the Modulation wheel function key, key F#3 (see Appendix B).

< Use the white data entry keys, F3 to B4 to enter the number of the controller you wish to assign to the wheel (see appendix C).

< Press C5 to accept the value and return to Performance Mode.

The Modulation wheel can be assigned a controller number from 0 to 131. Please see appendix C for more detail.

Note: pressing the ‘default key’ during data entry will cause the wheel to become assigned to Modulation (controller 1).

Part 2: The ProKeys 88sx as a MIDI Controller
