M-Audio PROKEYS 88SX [18/20] Appendix b
![M-Audio PROKEYS 88SX [18/20] Appendix b](/views2/1020650/page18/bg12.png)
22
Appendix B
Outline of the Function Keys
White Keys
C1
Cancel
D1 to E3
Channel Select
F3
Default
G3 to B4
Data Entry keys
C5
Enter
Black Keys
C#1
Data = Octave
D#1
Data = Transpose
F#1
Data = Program
G#1
Data = Bank LSB
A#1
Data = Bank MSB
C#2
Data = Channel
D#2
Data = Tuning
F#2
Panic
G#2
MIDI Out From USB
A#2
Local Off
C#3
Octave -
D#3
Octave +
F#3
Wheel Assign
G#3
Pedal Assign
A#3
Slider Assign
C#4
Transpose -
D#4
Transpose +
F#4
Program
G#4
Bank LSB
A#4
Bank MSB
Appendices
