- 64
Technical data
Jack 3.5 mm: ............................................................ Headphones 32-2000 ohm
Mini-DIN (AVS) Video IN: ................................................................Y/C (S-VHS/Hi 8)
............................................................CVBS (VHS/8 mm)
Cinch (yellow) Video IN: .............................................................CVBS (VHS/8 mm)
Cinch (white/red) Audio IN: ..............................................................L (white) / R (red)
2 x IEC socket 75 Ohm/5 V/80 mA: ............................... Antenna/cable/DVB-T/C
(1
2 x F socket 75 Ohm 13/18 V/350 mA: .............................ANT-SAT DVB-S/S2
(1
Cinch Audio IN max. 2Vrms: ..........................................................Centre
2 x Cinch AUDIO IN1: ..........................................................L (white) / R (red)
Jack 3.5 mm AUDIO IN2: ................................................................................L/R
2 x Cinch AUDIO OUT (level configuration-dependent): ......L (white) / R (red)
Cinch COMPONENT IN: .........................................................Cb/Pb signal
Cinch COMPONENT IN: ...........................................................Cr/Pr signal
Cinch COMPONENT IN: ................................................................ Y signal
Cinch Audio Digital IN (SPDIF): ..............................................Digital audio
Cinch Audio Digital OUT (SPDIF): ...........................................Digital audio
SUB-D AUDIO LINK: ............................................................. Multi-sound
(1
3 x HDMI Digital Video/Audio IN
Type A 19pole Standard 1.3: ......................Digital video and audio
SUB-D PC IN:................................................................PC/STB video signal
SUB-D RS-232C:................................................................Serial interface
(1
Mini-DIN SERVICE: .................................................................... Service/L-Link
Mini-DIN CONTROL: ................................................ Rotating stand control
(1
USB USB 2.0: ..........................................................Standard JPEG files
(1
CI-Slot Common Interface: .......................................... Slot for CA module
Jack 3.5 mm: IR-Link .......................................... Output for infrared transmitter
(1
Electrical data
Chassis designation: ........................................................................................... L 2712
Power supply: ........................................................................220 V – 240 V/50–60 Hz
Tuner: .................................................................................. VHF/UHF/cable/hyperband
Range:.......................................................................................... 45 MHz to 860 MHz
Station storage locations incl. AV and radio: ......................................................... 4000
TV standards: .................................................................................. B/G, I, L, D/K, M, N
Colour standard: ........................................ SECAM, PAL, NTSC, NTSC-V, PAL-V (60 Hz)
Sound standard ................................................. Mono/stereo/2-sound/Nicam B/G, I, L
Nominal audio output (sine / music): ............................................ 2 x 20 W / 2 x 40 W
Lower limit frequency of the speakers ................................................................. 90 Hz
Teletext: .......................................................................................... TOP/FLOF Level 2.5
Page memory ........................................................................................................2000
Digital teletext (only in UK / IRL with active MHEG-5 software) .......................MHEG-5
Connections (max. equipment)
Mains socket: ......................................................................................... Supply voltage
EURO-AV 1 Video IN: ..........................................................................Y/C (S-VHS/Hi 8)
........................................................................CVBS (VHS/8 mm)
Video OUT: ...................................................................CVBS (VHS/8 mm)
.......................................................................Y/C (S-VHS/Hi 8)
Audio IN: ...............................................................................................L/R
Audio OUT: ...........................................................................................L/R
EURO-AV 2 Video IN: ..........................................................................Y/C (S-VHS/Hi 8)
........................................................................CVBS (VHS/8 mm)
..............................................................................................RGB
Video OUT: ...................................................................CVBS (VHS/8 mm)
................................................ Y/C, (only with SVHS Link Plus)
Audio IN: ...............................................................................................L/R
Audio OUT: ...........................................................................................L/R
General data
Type Art 37 SL Full-HD
+
100 Art 42 SL Full-HD
+
100 Art 47 SL Full-HD
+
100
Article number 68423xxx 68402xxx 68403xxx
Dimensions for device without stand (W x H x D) in cm
Dimensions for device with stand (W x H x D) in cm
93.3 x 63.3 x 9.0
93.3 x 67.2 x 30.1
104.6 x 70.3 x 9.0
104.6 x 74.3 x 30.1
116.5 x 75.8 x 9.5
116.5 x 79.4 x 30.1
Weight for device without stand (approx.) in kg
Weight for device with stand (approx.) in kg
16.9
18.9
25.5
27.5
29.0
31.0
Display Full HD 100Hz Slim LCD technology Full HD 100Hz Slim LCD technology Full HD 100Hz Slim LCD technology
Picture diagonal in cm/picture format 94 / 16:9 106 / 16:9 119 / 16:9
Resolution in pixels 1920 x 1080 1920 x 1080 1920 x 1080
Dynamic contrast ratio 10,000:1 10,000:1 10,000:1
Static contrast ratio 1,300:1 1,300:1 1,300:1
Viewing angle horizontal and vertical 178° 178° 178°
Power consumption (EN 62087:2009)
Power consumption "On" (W) without / with DR
+
Power consumption in standby mode (W)
Power consumption when the set is turned off (W)
140 / 145
0,9
0
190 / 195
0,7
0
210 / 215
0,7
0
Ambient temperature (Celsius) 5° – 35°
Relative humidity (non-condensing) 20 – 80%
Air pressure 800 – 1114 hPa (0 – 2000 m above sea level)
(1
Equipment variants and upgrade possibilities see page 66.
