- 10
Terminology from the World of Discs
Title
A title is the main content of the film of music album. It is simple to access using
the assigned title number.
Chapter
A chapter are parts of a film or music track which are part quantities of a title. It
is simple to access one using the assigned chapter number.
Messages
During operation you may see FUNCTION NOT POSSIBLE on the screen. This
means that the required function is (possibly momentarily) not available.
Using the remote control for the first time
To insert or change the batteries, press on the arrow. While doing so, simply
slide the battery compartment lid down and remove it. Insert alkali manganese
batteries LR 03 (AAA) and ensure the correct position of + and –. Slide the cover
on again from the bottom.
Resetting the unit
If one of the following problems occurs
The unit is connected but can not be switched on or off.
The display on the console is not working.
The Player is not working normally,
you can reset the Player as follows:
Press the button on the unit for at least 8 seconds. The unit will
switch itself off or unplug it from the mains; wait for at least 20
seconds and then connect the cable again.
Press the button again to switch the unit back on.
•
•
•
Connecting up – General
➠ Depending on the TV set and the other units that you want to connect, there
are several options available for connecting the Player to your TV set. Only use
the connections described in the following.
➠ If applicable, read the accompanying documentation for your TV set, your
audio system and other units to make the connections described below.
➠ Do not connect the AUDIO OUT socket of the Player to the Phono In socket
of the audio system.
Connecting to the TV set
➠ The Blu-ray Player must be registered in the connection assistant if you have
a Loewe TV set.
HDMI connection
Using the enclosed HDMI cable, connect the socket HDMI OUT of the Player to
the HDMI input socket on the TV set (for Loewe TVs, socket HDMI 2). Make the
settings as described in page 15/16.
Component Video Connection
Using a Y Pb Pr cable (can be obtained from specialist retailers), connect the
COMPONENT VIDEO OUT sockets on the Player to the corresponding input
sockets on the TV set.
S Video Connection
Using an S video cable (can be obtained from specialist retailers), connect the
S-VIDEO AV OUT socket of the Player with the S Video input socket of the TV
set.
Video Connection
Using a cinch cable (can be obtained from specialist retailers), connect the
VIDEO AV OUT socket of the Player with the S Video input socket of the TV set.
Analogue Stereo Audio Output
Using a stereo cinch audio cable (can be obtained from specialist retailers), connect
the 2CH AUDIO AV OUT sockets of the Player to the stereo AUDIO-IN sockets
on the TV set.
Analogue 5.1 Audio Output
Using a 6 pin cinch audio cable (can be obtained from specialist retailers) , connect
the 5.1CH AUDIO AV OUT sockets of the Player to the 5.1 surround AUDIO-IN
sockets on the TV set.
Digital Audio Output
Connect the COAXIAL or OPTICAL DIGITAL AUDIO OUT socket of the Player to
the DIGITAL IN socket of the surround amplifier.
The Basics
