En-30

MS-7526 Mainboard

DIMM1/2 Memory SPD Information

Press <Enter> to enter the sub-menu.

These items display the current status of the current DIMM Memory speed

informations. They are read only.

Advanced Memory Setting

Setting to [Auto] enables DRAM timings automatically to be determined by BIOS

based on the configurations on the SPD (Serial Presence Detect) EEPROM on the

DRAM module.

1N/2N Memory Timing

This item controls the SDRAM command rate. Select [1N] makes SDRAM signal

controller to run at 1N (N=clock cycles) rate. Selecting [2N] makes SDRAM signal

controller run at 2N rate.

FSB/DRAM Ratio

This item will allow you to adjust the ratio of FSB to memory.

Adjusted DRAM Frequency (MHz)

It shows the adjusted Memory frequency. Read-only.

ClockGen Tuner

Press <Enter> to enter the sub-menu.

CPU Clock Drive/ PCI Express Clock Drive

These items are used to select the CPU/ PCI Express clock amplitude.

CPU CLK Skew/ MCH CLK Skew

These items are used to select the CPU/ North Bridge chipset clock skew. They

can help CPU to reach the higher overclocking performace.

Adjust PCI Frequency (MHz)

This field allows you to select the PCI frequency (in MHz).

Auto Disable DRAM/PCI Frequency

When set to [Enabled], the system will remove (turn off) clocks from empty DIMM and

PCI slots to minimize the electromagnetic interference (EMI).

DRAM Voltage (V) / NB Voltage (V) / VTT FSB Voltage(V)

These items are used to asjust the voltage of CPU, Memory, FSB and chipset.
