Chapter 1. Introduction

No. Component Description

1 Power Socket The power cord to the AC source plugs in here.

2 Power Switch This is a standard rocker switch that powers the KH2508

A /

KH2516

A on and off.

3 Daisy Chain

Ports

When daisy chaining units (see KVM Adapter Cable

Installation Diagrams cont., page 17), the daisy chain cables

plug in here. The port on the left is the Chain In port; the port

on the right is the Chain Out port.

4 Grounding

Terminal

The wire used to ground the unit connects here.

5Console 1

Ports

The KH2508

A / KH2516A supports two independent

consoles. If this is a single station installation, or if this is the

first station of a daisy chained installation, the keyboard,

monitor, and mouse that make up Local Console 1 plug into

section no. 5 and Local Console 2 plugs into section no. 6.

You can use any combination of PS/2 and USB keyboards

and mice for the console.

6Console 2

Ports

7 KVM Port

Section

The Cat 5e/6 cables that link to the KVM adapter cables

(which link to the computers) plug in here.
