KH2508A / KH2516A User Manual
v
Package Contents
The KH2508A / KH2516A package consists of:
1 KH2508
A or KH2516A Cat 5 High-Density KVM Switch
1 Firmware Upgrade Cable
1Power Cord
1 Rack Mount Kit
1 Foot Pad Set (4 pcs.)
1 User Instructions*
Check to make sure that all of the components are present and in good order.
If anything is missing, or was damaged in shipping, contact your dealer.
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the switch or to any other
devices on the KH2508
A / KH2516A installation.
* Features may have been added to the KH2508A / KH2516A since this manual
was published. Please visit our web site to download the most up-to-date
version of the manual.
Copyright © 2010–2016 ATEN® International Co., Ltd.
Manual Date:2016-01-15
Altusen and the Altusen logo are registered trademarks of ATEN International Co., Ltd. All rights reserved.
All other brand names and trademarks are the registered property of their respective owners.
