Chapter 4. OSD Operation
35
SET CAT 5
LENGTH
Lets you specify how long the Cat 5e/6 cable between the port and the
KVM adapter cable is. Press [Spacebar] to cycle through the cable
length settings:
S: Short – for up to 25 m
M: Medium – for between 20 and 35 m
L: Long – for above 35 m
An S, M, or L appears next to the port to indicate the choice.
SET
KEYBOARD
LANGUAGE
Sets the keyboard language layout for the computers attached to each
port. Press [Spacebar] to cycle through the language choices. The
default keyboard language layout is English (US).
FIRMWARE
UPGRADE
In order to upgrade the KH2508A / KH2516A’s and adapter cables
firmware (see The Firmware Upgrade Utility, page 53) you must first
enable Firmware Upgrade mode with this setting.
When you bring up this menu, the current firmware version levels
display. Select Y to enable Firmware Upgrade mode, or N to leave this
menu without enabling it.
SET LOGIN
MODE
This function allows the administrator to request users to login or not.
When the login dialog box is disabled, the system disables the login/
logout function. If the system is re-started, the login/logout function
remains disabled. Select Y to require users to login/logout of the
system. Select N to disable the login/logout function.
OSD CONF
BACKUP/
RESTORE
This option lets you backup the current OSD configuration of the
KH2508A / KH2516A, and restore it when necessary. Storing the OSD
configuration settings is useful when deploying more than one
installation that uses the same settings. For more information see OSD
Configuration Backup/Restore, page 61.
MFG The MFG number is an internal serial number used by ATEN’s factory
and technical support staff to identify products. This number does not
affect products’ warranty. If your product requires after-sales services,
you may provide the MFG Number to ATEN’s sales or technical
support staff to identify the product and model number.
Setting Function
