17
Chapter 4
Hotkey Operation
The CS1922 / CS1924 provides an extensive, easy-to-use, hotkey function that
makes it convenient to control and configure your KVM installation from the
keyboard. Hotkeys provide asynchronous (independent) switching of the
KVM, USB hub, and audio focus. Therefore, you can give one computer the
KVM focus, another the USB hub focus, while a third has the audio focus.
Port Switching
All port switches begin with tapping the Scroll Lock key twice. The tables
below describe the actions that each key combination performs.
Note: If using the Scroll Lock key conflicts with other programs running on
the computer, the Ctrl key can be used, instead. See Alternate Port
Switching Keys, page 21, for details.
Cycling Through the Ports
Hotkey Action
[Scroll Lock] [Scroll Lock]
[Enter]
Brings the KVM, USB hub, and audio focus from the port
that currently has the KVM focus to the next port on the
installation (1 to 2; 2 to 3; 3 to 4; 4 to 1).
Note: the KVM, USB hub, and audio focus all go to this
port even if they were on different ports to begin with.
[Scroll Lock] [Scroll Lock]
[K] [Enter]
Brings only the KVM focus from the port that currently
has it to the next port on the installation. The USB and
audio focus remain where they are.
[Scroll Lock] [Scroll Lock]
[U] [Enter]
Brings only the USB hub focus from the port that
currently has it to the next port on the installation. The
KVM and audio focus remain where they are.
[Scroll Lock] [Scroll Lock]
[S] [Enter]
Brings only the audio focus from the port that currently
has it to the next port on the installation. The KVM and
USB hub focus remain where they are.
