Aten CS1944 [10/47] Features
![Aten CS1942 [10/47] Features](/views2/1211067/page10/bga.png)
CS1942 / CS1944 User Manual
2
Features
One Dual-View USB console independently and simultaneously controls
two/four Mini DisplayPort computers and two additional USB devices
2-Port USB 2.0 hub built in, fully compliant with USB 2.0 specifications
Computer selection via front touch panel/hotkey/mouse wheel*
Mini DisplayPort 1.1a & HDCP compatible
Full bass response provides a rich HD digital surround sound experience
via Mini-TOSLINK connections
Superior video quality - supports up to 2560 x 1600 resolution and 3D
video up to 1920x1080 resolution at 120Hz
Nvidia 3D Vision Ready
USB Quick Charge Feature (front panel USB port)
Independent switching of USB peripherals, audio, and KVM focus
Keyboard and Mouse support emulation and bypass
Auto scan feature
Power on Detection
Mac keyboard support and emulation**
Multilingual keyboard mapping - Supports English, Japanese, and French
keyboards
Multiplatform support- Windows, Linux and Mac
Upgradeable firmware via USB interface
*Mouse port switching only works with 3-key USB mouse wheel in emulation
mode.
**PC keyboards emulate Mac keyboards, and Mac keyboards only work with
their own computers.
