Aten CS1944 [12/47] Operating systems

CS1942 / CS1944 User Manual

Operating Systems

Supported operating systems are shown in the table, below:

OS Version

Windows 2000 SP4 and higher, XP, 2003, 2008, Vista

(x64, x86), Windows 7 (x64, x86)

Linux RedHat Fedora and higher, RHEL AS 4, RHEL 5,

RHEL 5

SuSE 10 and higher, OpenSUSE 10.2; SLES 10 SP1

Debian 3.1, 4.0

Ubuntu 7.04, 7.10

UNIX FreeBSD 5.5, 6.1, 6.2

Novell Netware 6.0, 6.5

Mac 9.0, 9.1, 10.1, 10.2, 10.3, 10.4, 10.5
