CS1942 / CS1944 User Manual
22
Keyboard Operating Platform
The CS1942 / CS1944’s default port configuration is for a PC compatible
keyboard operating platform. If your console uses a PC compatible keyboard
and you have a Mac attached to a port, for example, you can change the port’s
keyboard operating platform configuration so that the PC compatible keyboard
emulates the Mac keyboard. In addition the keyboard can be set to replicate
different language keyboards. The procedures are as follows:
1. Bring the KVM focus to the port you want to set.
2. Invoke HSM (see page 20).
3. Press and release the appropriate Function key (see table below). After
completing this procedure, you automatically exit HSM.
List Switch Settings
To see a listing of the current switch settings, do the following:
1. Open a text editor or word processor and place the cursor in the page
window.
2. Invoke HSM (see page 20).
3. Press and release [F4] to display the settings.
Function Key Operation
[F2] Enables Mac keyboard emulation, see page 27, for
details.
[F6] [nn] [Enter] Sets the keyboard language layout. Where “nn” is the
two digit number that represents the keyboard language
code:
U.S. English: 33
French: 08
Japanese: 15
[F10] Auto detects the keyboard operating platform (for PC
compatible systems). Activates Pass Through keyboard
mode (keystrokes are sent directly to the computer
instead of through the Mac emulator).
