CS1942 / CS1944 User Manual
36
Specifications
*Port switching only works with 3-key USB mouse wheel in emulation mode.
Function CS1942 CS1944
Computer Connections 2 4
Port Selection Touch Panel, Hotkey, Mouse*
Connectors Console
Ports
Keyboard 1 x USB Type A F (Black, rear panel)
Video 2 x Mini DisplayPort F (Black)
Mouse 1 x USB Type A F (Black, rear panel)
Speaker 1 x Mini-TOSLINK Jack F (Black, rear panel)
1 x 3.5mm Audio Jack F (Green, front panel)
Microphone 1 x Mini-TOSLINK Jack F (Black, rear panel)
1 x 3.5mm Audio Jack F (Pink, front panel)
KVM Ports Keyboard/
Mouse
2 x USB Type B F (White) 4 x USB Type B F (White)
Video 4 x Mini DisplayPort F
(Black)
8 x Mini DisplayPort F
(Black)
Speaker 2 x Mini-TOSLINK Jack F
(Black)
4 x Mini-TOSLINK Jack F
(Black)
Microphone 2 x Mini-TOSLINK Jack F
(Black)
4 x Mini-TOSLINK Jack F
(Black)
USB 2.0 Hub 2 x USB Type A F (White; 1 x Front panel, 1 x Rear
panel)
Power 1 x DC Jack
Switches Selected 3 x Point Touch Panel 5 x Point Touch Panel
LEDs KVM 2 x Orange 4 x Orange
Audio 2 x Green 4 x Green
USB 2 x Green 4 x Green
Emulation Keyboard/Mouse USB
Video DP: 2560 x 1600 resolution @ 60Hz, or 3D Display
1920 x 1080 resolution @ 120Hz
Scan Interval 1 ~ 99 seconds (Default: 5 seconds)
Power Consumption DC 5.3V, 6.68W DC 5.3V, 8.63W
Environment Operation Temp. 0–50ºC
Storage Temp. -20–60ºC
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Plastic
Weight 556 g 614 g
Dimension (L x W x H) 197 x 197 x 44.7 mm
