CS1942 / CS1944 User Manual

5. Using the Mini DisplayPort 1.1a cable, plug the Mini DisplayPort

connector into an available Mini DisplayPort “A” socket on the KVM port

(CPU 1, CPU 2, etc.) section of the switch , then plug the USB 2.0 cable,

and microphone/speaker cables into their corresponding sockets.

Note: Verify that all the plugs are in the same KVM Port sockets (all in

CPU 1, all in CPU 2, etc.). Each socket is marked with an

appropriate icon.

6. At the other end of the cable sets from step 5, plug the Mini DisplayPort

1.1a cable, USB 2.0 cable, and microphone/speaker cables into their

respective ports on the computer.

7. Using another Mini DisplayPort 1.1a cable, plug the Mini DisplayPort

cable connector into the Mini DisplayPort socket “B” on the same KVM

port (CPU 1, CPU 2, etc.) section of the switch.

8. At the other end of the Mini DisplayPort 1.1a cable from step 7, plug the

monitor cable into its respective port on the computer.

Note: Repeat steps 5, 6, 7, and 8 for each dual-screen PC system you are

installing.

9. Plug your USB peripherals into the front (a) or rear (b) USB peripheral

ports (optional).

10. Plug the power adapter that came with your switch into an AC power

source, then plug power adapter cable into the switch’s Power Jack.

11. Power on the computers.
