Chapter 1. Introduction
7
RJ-45 to Serial Adapters
Cat 5e (or higher) cable is required to connect the Serial Console Server to
the RJ-45 Serial Adapters (see page 25).
The various RJ-45 to Serial Adapters offered by ALTUSEN are shown in
the table, below:
RJ-45 to RJ-45 Cat 5e Cables
For serial devices with DB9 or DB25 connectors, use standard straight-
through cables.
For serial devices with RJ-45 connectors, use rollover cable or specialized
pinout cable.
Model Connector Interface
SA0141 RJ-45 to DB9-F DTE to DTE
SA0142 RJ-45 to DB9-M DTE to DCE
SA0143 RJ-45 to DB25-F DTE to DTE
SA0144 RJ-45 to DB25-M DTE to DCE
SA0145 RJ-45 to DB9-M DTE to DTE
SA0146 RJ-45 to DB9-F DTE to DCE
SA0147 RJ-45 to DB25-M DTE to DTE
SA0148 RJ-45 to DB25-F DTE to DCE
SA0149 RJ-45 to DB9-M PN0108 to PN7/PN5
SA0150 RJ-45 to DB9-F PN7/PN5/SN to
PN0108
SA0151 DB9-F to RJ-45 PC to PN7/PN5
