Aten SN0116A [5/165] Package contents

Serial Console Server User Manual

Package Contents

The Serial Console Server package consists of:

SN0108A / SN0116A

1 SN0108A / SN0116A Serial Console Server

1 SA0142 Serial Adapters (RJ45-F to DB9-M; DTE to DCE)

1 SA0141 Serial Adapter (RJ45-F to DB9-F; DTE to DTE)

1 CD-ROM with management software and Real COM drivers

1 Laptop USB Console Cable

2 Power Cords (AC models)

1 Rack Mount Kit

2 Lok-U-Plugs

1 User Instructions*

SN0132 / SN0148

1 SN0132 / SN0148 Serial Console Server

1 SA0142 Serial Adapters (RJ45-F to DB9-M; DTE to DCE)

1 SA0141 Serial Adapter (RJ45-F to DB9-F; DTE to DTE)

1 SA0150 Serial Adapter (RJ45-F to DB9-M; PN0108 PON IN)

1 Laptop USB Console Cable

2 Power Cords (AC models)

1 Rack Mount Kit

1 Foot Pad Set (4 pcs.)

1 User Instructions*
