Serial Console Server User Manual
vi
SN9108 / SN9116
1 SN9108 / SN9116 Serial Console Server
1 CD-ROM with management software and Real COM drivers
1 Power Cords (AC models)
1 Rack Mount Kit
1 Lok-U-Plugs
1 User Instructions*
Check to make sure that all of the components are present and in good order.
If anything is missing, or was damaged in shipping, contact your dealer.
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the Serial Console Server or to
any other devices on the installation.
* Features may have been added since this manual was published. Please visit
our website to download the most up-to-date version of the manual.
Copyright © 2015 ATEN® International Co., Ltd.
Manual Date: 2015-09-23
Altusen and the Altusen logo are registered trademarks of ATEN International Co., Ltd. All rights reserved.
All other brand names and trademarks are the registered property of their respective owners.
