Aten VS461 [12/19] Ir remote control unit

- 12 -

IR Remote Control Unit

No. Component Description

1 Power Jack The power adapter cable plugs in here.

2 Media Output

Section

The cables from your DVI Video Display and Audio jacks

plug in here. Each connector is marked with an appropriate

icon to indicate itself.

3 Media Input

Section

The cables that link your media source devices to the VS-

261 / VS-461 plug into the ports in this section. Each

section is comprised of a DVI-I connector and two speaker

jacks. When connecting DVI and audio cables from your

sources, be sure that the DVI cable and audio cables from

a device all plug into the same port section (e.g. all in Port

1, etc.).
