- 15 -

Video Port Switching

There are two convenient methods for switching among video

sources: Manual and the Remote Control.

Manual Selection

To select a source device, press and release the front panel

pushbutton that corresponds to the port that the device is

connected to.

Remote Control Selection

 Press the Port Up or Port Down button on the remote control

unit to cycle among the source devices. Each time you press

the button, the media focus switches from the current port to

the next port (Port Up) or the previous port (Port Down).

 To switch directly to a source device, press the numerical

button (1, 2, 3, or 4) that corresponds to the port that the

device is connected to.

Note: 1. Pressing button 3 or 4 has no effect on the VS-261.

2. The infrared signal range is 6 meters (max.)

3. You must aim the remote control unit at the IR

Receiver located on the switch's front panel (see p.

9). For optimum performance, make sure there is a

clear line-of-sight between the control unit and the

receiver.
