VC010 / VC060 / VC080 User Manual
3
Requirements
The following equipment is required for a complete VC010 / VC060 / VC080
installation:
Source Devices(s)
One of the following, depending on the unit you have:
VC010: VGA device and HDB-15 connector with 3.5mm audio connector
VC060: A DVI enabled source device
VC080: HDMI Type A connector(s)
Display Device
One of the following, depending on the unit you have:
VC010: A display device with a HDB-15 Female connector
VC060: A DVI enabled display device
VC080: HDMI display device or receiver with an HDMI Type A input
connector
Cables
Firmware Upgrade cable
One of the following, depending on the unit you have:
VC010: VGA cable
VC060: DVI-I or DVI-D cable
VC080: HDMI cable
