VC010 / VC060 / VC080 User Manual
vii
About this Manual
This User Manual is provided to help you get the most from your VC010 /
VC060 / VC080 system. It covers all aspects of installation, configuration and
operation. An overview of the information found in the manual is provided
below.
Chapter 1, Introduction, introduces you to the VC010 / VC060 / VC080
system. Its purpose, features and benefits are presented, and its front and back
panel components are described.
Chapter 2, Hardware Setup, describes how to set up your VC010 / VC060
/ VC080 installation. The necessary steps are provided.
Chapter 3, Operation, explains the fundamental concepts involved in
operating the VC010 / VC060 / VC080 via the front panel pushbuttons, remote
controlled On-Screen Display (OSD), or through the RS-232 serial interface.
Chapter 4, The Firmware Upgrade Utility, explains how to use this
utility to upgrade the VC010 / VC060 / VC080's firmware with the latest
available versions.
An Appendix, provides specifications and other technical information
regarding the VC010 / VC060 / VC080.
