Hyundai H-CMD4026 Black/R [11/45] Operation
![Hyundai H-CMD4026 Black/R [11/45] Operation](/views2/1021200/page11/bgb.png)
11
Operation
VOLUME knob on the panel to select the audio
setting item. Press ENTER button or RIGHT
cursor button on the RC or OK button on the
panel to enter the selected item.
Press LEFT/RIGHT buttons on the RC or
rotate VOLUME knob on the panel to adjust the
audio setting. Press SEL button on the RC again
to save the setting and return to current mode.
If turn off the power, all the settings
of each mode will be saved. If turn off the
ACC power, all the settings will be clear and
become factory default setting. If you don’t
adjust setting within several seconds after
selecting the desired setting item, the unit will
automatically return to the current mode.
System setup
Press MENU button on the panel or RC to
enter Setting Menu. Press UP/DOWN cursor
buttons on the RC or rotate VOLUME knob on
the panel to select a menu page. Press ENTER
button or RIGHT cursor button on the RC or
press OK button on the panel to enter the page.
Press UP/DOWN cursor buttons on the RC or
rotate VOLUME knob on the panel to select an
item, then press ENTER button on the RC or OK
button on the panel to adjust the setting.
Press MENU button to return to the last
setting list.
AUDIO MENU
• Bass: Support 10 levels. Default level is 0.
• Treble: Support 10 levels. Default level is 0.
• Balance: Support 10 levels for each left
and right channel. Default is left equal to right.
• Fader: Support 10 levels for each front and
rear channel. Default is front equal to rear.
• EQ DSP: FLAT => CLASSICS => POP =>
ROCK => DSP OFF.
PICTURE MENU (available in DVD/USB/
Card modes only)
• Red: Adjust level of red color. Support 50
levels. Default level is 25.
• Green: Adjust level of green color. Support
50 levels. Default level is 25.
• Blue: Adjust level of blue color. Support 50
levels. Default level is 25.
• Brightness: Adjust level of screen
General operations
Reset the unit
Operating the unit for the first time or after
replacing the car battery, you must reset the
unit. Press RESET button (hole) with a pointed
object (such as a ballpoint pen) to set the unit
to initial state.
When some errors occur, you can also
press RESET button to resume to normal,
and it will erase the clock setting and some
memorized functions.
Turning the unit on/off
Press any button on the panel or the RC
(except OPEN button) to turn on the unit. Press
and hold POWER/MUTE button on the panel
or press POWER button on the RC to turn off
the unit.
Mode selection
Repeatedly press MODE button on the RC
or on the panel to select a mode: Tuner =>
DVD => USB => Card => AV IN.
The DVD, Card and USB modes are
only available when corresponding storages
are inserted into the unit.
Mute function
Press MUTE button on the RC or POWER/
MUTE button on the panel to turn off the
sound. “MUTE” appears on the display. Press
the button again or adjust volume to resume
the sound output.
Volume control
Press VOL+/VOL- buttons on the RC or
rotate VOLUME knob on the panel to decrease
or increase sound volume level.
Setting the sound characteristics
Press SEL button on the RC to select the
audio setting menu: BASS =>TREBLE =>
BALANCE => FADER => EQ. Press UP/
DOWN cursor buttons on the RC or rotate
