12 13
Operation Operation
brightness. Support 50 levels. Default level is 25.
• Contrast: Adjust level of screen contrast.
Support 50 levels. Default level is 25.
• Sharpness: Adjust level of screen
sharpness. Support 15 levels. Default level is 10.
• Screen: Adjust screen aspect: 16:9 => 4:3
=> FULL.
• Color reset: Resume color default status.
(Select YES or NO with cursor buttons, press
ENTER button on the RC or OK button on the
panel to confirm).
EXPERT MENU
• DX: Set search radio station by DX or
LOCAL mode. DX => LOCAL.
• Stereo: Set radio audio at STEREO or
MONO mode, STEREO => MONO.
• Beep: Set press button sound. 2ND =>
ALL => OFF.
• Loud: Set loudness on or off. OFF => ON.
• Subwoofer: Set subwoofer ON or OFF.
• Backlight: Set OSD backlight: HIGH =>
LOW => MID.
• OSD color: Set OSD color: DARK BLUE
=> VIOLET => LIGHT BLUE.
CLOCK MENU
• Clock: Set CLOCK display time or not.
OFF/ON.
• Clock Hour: set clock 12H/24H.
• Clock adjust: Set CLOCK ADJUST time.
Subwoofer
Connect a subwoofer to this unit using the
Subwoofer output of this unit. For subwoofer
operation an external amplifier is required.
AV in jack
AV jack is intended to receive audio and video
signals by connecting to external device.
Radio operations
Band selection
Press BND/RDM button on the RC or BAND
button on the panel to switch to the bands in
the following order: FM1 - FM2 - FM3 (OIRT) –
MW (AM).
Manual/automatic tuning
• Manual tuning: Press and hold SEEK- /
SEEK+
buttons on the RC to enter manual
tuning mode. MANUAL will be displayed.
Press these buttons repeatedly to change the
frequency upward or downward step by step.
• Automatic tuning: Press repeatedly SEEK-
/SEEK+ buttons on the RC or press
and hold these buttons on the panel to start
automatic seeking for an available radio station
downward or upward. After being found the
station will be played. To stop seeking, press
one of these buttons again.
Programming stations
• There are 6 numbered preset buttons on
the RC, with which you can store and recall
stations for each band (18 FM, 6 AM). Select
a station, then press and hold a preset button.
The station will be saved in the memory under
the corresponding number. To recall a stored
station, press the corresponding preset button.
• You also can save stations in the memory
with MEM/
button on the front panel. When
the needed frequency is found, press MEM/
,
then rotate VOLUME knob to select a memory
position (PRESET 1 - 6) and press OK button
to confirm saving.
Auto memory store/Preset scan
Auto store: Select a band, press and hold
P.SCN/RPT button on the RC to enter auto
store mode. The radio will automatically store 6
stations to the 6 preset memories of the current
band. To stop auto store, press the button
again.
During auto station preset, the unit will
search and store stations with the strong signal
first, and then weaker signal stations until the
memories are full.
Preset scan: Select a band, press P.SCN/
RPT button on the RC to scan all preset
stations in the memories of the current band.
To stop preset scan, press the button again.
