Chapter 2

B150M-P73 USER MANUAL

Recommend memory configuration

Model

Sockets

DIMM1 DIMM2 DIMM3 DIMM4

1 DIMM ~ Populated ~ ~

1 DIMM ~ ~ ~ Populated

2 DIMMs ~ Populated ~ Populated

3 DIMMs Populated Populated ~ Populated

3 DIMMs ~ Populated Populated Populated

4 DIMMs Populated Populated Populated Populated

Due to Intel CPU spec definition, please follow the table above for

recommended memory configuration.

1. For best performance and compatibility, we recommend that users give

priority to the white DIMMs (DIMM2/DIMM4) when installing DIMMs.

2. We suggest users not to mix memory type. It is recommended to use the

same brand and type memory on this motherboard.
